Microscopes are a common instrument found in electronic assembly operations.  Microscopes are used for inspection and for assembly of very small objects.   It is critical that the microscope lenses remain clear and free of dust and other contamination.   When not in use, microscopes should be covered to protect the optics.

Some manufactures of microscopes provide covers for the time when the scopes are not in use.  Typically the covers are made of vinyl.  While vinyl may provide good protection from dust and fumes, it is a significant static generator.

The vinyl cover in the photo above shows an electrostatic voltage of -5,500 volts.   Once the cover is removed from the scope the voltage jumps even higher to -12,000 volts.

ANSI/ESD S2020, the industry standard for ESD control programs, states that all nonessential insulators should be removed from the ESD protected area.

Since it is critical that microscopes be covered when not in use, it could be argued that the microscope cover is a process essential insulator.  ANSI/ESD S2020, Section 8.3.1 states that the ESD control program “shall include a plan for handling process required insulators in order to mitigate field induced CDM damage.”

The standard goes on to say that if the field is greater than 2000 volts/inch it must be kept more than 12” from the ESD sensitive item.   If the microscope is not in use, but work on ESD sensitive devices is being performed at the station, the vinyl scope cover becomes a significant risk.   The vinyl cover becomes even a greater risk if it is removed while there are ESD sensitive items at the workstation.

The best solution is to replace the vinyl cover with a microscope cover that is ESD safe, such as the Transforming Technologies MC1221W.   This scope cover is constructed of ESD safe material and does not generate a significant charge.

Even when the cover is removed, the charge remains very low.

With Transforming Technologies’ MC1221W you can protect your microscope optics from contamination while keeping your work station ESD safe.

Email Transforming Technologies to protect your microscope with our Microscope Covers

Transforming Technologies is proud to announce the addition of the StaticCare ESD Hand Lotion to our line of ESD Products.

Static electricity can have a negative impact on your measurements when using a scale or balance. Static electricity can cause several measurement issues: values may fluctuate or gradually change; repeatably of measurements is poor; or values may be stable but inaccurate.  Static electricity is essentially an electrical charge at rest or an electrical charge that accumulates on an object when it is rubbed against another object producing friction. Static can be removed, or “discharged” with an ionizer.

The Staticmaster 2U500 Ionizing Cartridge is the only self powered stat

ic eliminator available today. The small device requires no airflow, makes it an ideal solution for in-balance ionization. The 2U500 is inherently balanced to zero volts – which helps ensure thorough static removal for accurate weighs every time.

Significantly enhances the static eliminating power of the 2U500 Ionizing cartridge. Extensive testing has shown that adding the Grounding Kit to your in-balance ionizer can significantly increase the performance of the static eliminator. An indispensable accessory for mounting a 2U500 cartridge in the Balance Chamber. Simply remove the protective layer of the double-sided tape and affix the E-Z Mount to the back wall of the chamber. Once the mount is attached, replacing the 2U500 Ionizing Cartridge is fast and easy.

Limited Warranty for our Ionizers and Test Equipment

Transforming Technologies expressly warrants that for a period of one (1) year from the date of purchase, Transforming Technologies ESD products will be free of defects in material (parts) and workmanship (labor). Within the warranty period, a unit will be tested, repaired or replaced at Transforming Technologies option, without charge. Call our Customer Service Department for a Return Material Authorization (RMA) and proper shipping instructions and address.

Our Mission

Transforming Technologies’ mission is to provide you with the highest quality ESD products in the industry. Occasionaly problems arise this We continuously research and develop new technology in static control so that we can provide you the best products possible. Our name is not a coincidence, it is our goal to transform the ESD industry and we do that one new and unique product at a time.

Transforming Technologies will be participating in the 2014 EOS/ESD Symposium September 7-11 at the Westin La Paloma Resort in Tucson, AZ.

Come visit us in Booth 510 in the exhibit hall to view several new products, talk ESD issues, or just to socialize.

The exhibit hours are:
Monday, September 8: 6:00 p.m. – 9:00 p.m.
Tuesday, September 9: 9:30 a.m. – 5:00 p.m.
Wednesday, September 10: 8:30 a.m. – 1:30 p.m.

Transforming Technologies participates regularly in the EOS/ESD Symposium as well as being very active on the ESD Association standard development committees.

Westin La Paloma – Location of the 2014 EOS/ESD Symposium

We look forward to seeing you in Tucson!

Transforming Technologies is proud to announce the addition of the WB5600 Series Anti-Allergy Wrist Strap Set to our line of ESD Products.

Our West Coast Warehouse is Open!

Transforming Technologies is proud to announce that we are now stocking our MT4500 Series Two Layer ESD Rubber on the west coast! This means reduced shipping costs, shorter transit times, and even BETTER service! You could save up to three days on transit time, and up to 65% on shipping cost!

For more information call 419-841-9552 or email info@transforming-technologies.com

Transforming Technologies is proud to announce the addition of the IN4000PE Flexible Neck Ionizing Nozzle to our line of ESD Products.

For price and availability on the IN4000PE Flexible Neck Ionizing Nozzle or for information on any products in Transforming Technologies full line of ESD products, please call 419-841-9552 or email info@transforming-technologies.com.
